MikroTik CRS418-8P-8G-2S+RM

Data sheet

10/100/1000 Ethernet Ports

17

PoE out

802.3af/at

Max. Power Consumption

215 W

Certifications

CE, EAC, ROHS

Product Code

CRS418-8P-8G-2S+RM

CPU Nominal Frequency

2208 MHz

CPU Core count

4

Size of RAM

1 GB

Voltage Monitor

Yes

PCB Temperature Monitor

Yes

License Level

5

CPU

IPQ-8072

Wireless Chip Model

20

Storage Size

128 MB

Architecture

ARM 64bit

CPU Temperature Monitor

Yes

Current Monitor

Yes

SFP+ Ports

2

Operating Temperature

-20°C to 70°C

Storage type

NAND

Max total out (A)

5.4 A

Max power consumption without attachments

28 W

USB Power Reset

Yes

USB slot type

USB 3.0 type A

Max USB current (A)

1

Number of AC inputs

2

AC input range

100-240

Mode button

Yes

USB Port

1

PoE-out ports

Ether9 - Ether16

Number of 1G Ethernet ports with PoE-out

8

MTBF

Approximately 200'000 hours at 25C

Serial console port

RJ45

Max out per port output (input 18-30 V)

1.1 A

Max out per port output (input 30-57 V)

0.56 A

IPsec hardware acceleration

Yes

Total output power

150

Cooling type

4 fans

Total output current

5.4

Switch chip model

98DX226S

Number of PSU slots

2

Frequency (Hz)

50-60
